The AWS CloudWatch MCP Server lets Corunner query your AWS metrics, alarms, PromQL data, and CloudWatch Logs Insights. Corunner uses a cross-account IAM role and does not require your AWS access keys.

​
What you get

  • Read CloudWatch metrics
  • Read alarm details and alarm history
  • List metrics
  • Query CloudWatch Logs Insights
  • Read log anomaly information
The connection is read-only. Corunner cannot create, update, or delete CloudWatch resources.

​
Before you start

You need permission to create an IAM role in the AWS account that contains the CloudWatch data. You also need the AWS region where Corunner should query CloudWatch.

​
Create the AWS IAM role

Create a new IAM role for Corunner in AWS. When AWS asks for a trust policy, paste the following policy. Replace <CORUNNER_AWS_ACCOUNT_ID> with the AWS account ID provided by Corunner. Keep the external ID exactly as shown in the CloudWatch connection dialog.

​
IAM trust policy (AssumeRole)

Attach the following inline policy, or an equivalent customer-managed policy, to the role. It grants only the read permissions required by the connection.

​
Read-only IAM permission policy

After you create the role, copy its ARN. It looks like this:
You will paste this IAM Role ARN into Corunner. Do not paste an AWS access key or secret key.

​
Connect CloudWatch

1

Open the CloudWatch connection

In the Corunner web app, open Integrations, select MCP Servers, and choose AWS CloudWatch.
2

Enter the connection details

Enter a connection name, choose the AWS region, and paste the IAM Role ARN for the role you created. Corunner displays the external ID and the policies required for the connection.
3

Configure AWS and connect

Confirm that the trust policy uses the displayed external ID and that the read-only permission policy is attached to the role. Return to Corunner and click Connect. Corunner tests the role before saving the connection.
AWS CloudWatch connection form showing the connection name, AWS region, IAM Role ARN, and external ID fields

Enter the connection name, AWS region, and IAM Role ARN.


AWS CloudWatch connection form showing the external ID and IAM Trust Policy

Copy the external ID and IAM trust policy into AWS IAM.


AWS CloudWatch connection form showing the read-only IAM Permission Policy and Test Connection button

Copy the read-only IAM permission policy, then test the connection.

​
Troubleshooting

  • Access denied: Verify that the IAM Role ARN is correct and that the role trust policy names the Corunner task role.
  • Invalid external ID: Copy the external ID from the current CloudWatch connection dialog. It must match the value in the trust policy exactly.
  • No data returned: Confirm that the selected AWS region contains the metrics or log groups you want to query.

​
Manage this connection

Open Integrations in the Corunner web app, then find AWS CloudWatch under the MCP Servers tab.
